Large 28.25mm dual-diaphragm capsule |
 |
Circuit: Solid-State low-noise FET |
 |
Cardioid, Omni & Figure-8 polar pattern switch |
 |
Type: Pressure gradient condenser |
 |
+10dB gain switch |
 |
Polar Pattern: Cardioid, Omnidirectional & Figure-8 |
 |
-10dB attenuation switch |
 |
Freq. Response: 25Hz-20KHz |
 |
Low noise FET |
 |
Dynamic Range: 120dB minimum |
 |
High resolution capacitors |
 |
Impedance: <200 ohms |
 |
Custom wound output transformer
|
 |
Max. SPL: 0.5%THD@1000Hz: 130dB |
|
|
 |
Self-noise level: < 15dB(A) |
|
|
 |
Sensitivity:16mV/Pa OR -36±2dB 0dB=1V/Pa 1000Hz |
|
|
 |
Special Features:-10 dB attenuation and +10dB gain |
|
|
 |
Requires 48v Phantom power |
